DT80 B / DT100 B und DT80 T / DT100 T Series
DT 80 / DT 100 and DT80T / DT100T electrode suction systems guarantee fast, effective and comfortable ECG operation. These specific electrode suction systems are compatible to nearly all ECG devices. An assembly onto various trolleys, especially the MESA MW 1250-60 trolley series is possible.
DT80 B / DT 100 B electrode suction system
DT80T / DT 100T electrode suction system
MESA Medizintechnik is authorized strässle & co Partner
DT80 B / DT100 B and DT80 T / DT100 T Serie
DT 80 B / DT 100 B and DT80 T / DT100 T series
The DT 80 B / DT 100 B and DT 80 T / DT100 T series have a solid and very robust
spring swivel arm. The DT 80 T and DT 100 T series telescope arms are constructed
for heavy duty and sophisticated use. Quality and perfomance are outstanding
characteristics of these systems.
- Functional suction arm and suction head design
- Stabile turnaround suction arm - easy to operate
- Fully automatic regulation of selected suction intensity level
- Automatic leakage compensation
- Low noise vacuum pump
- Switchable vacuum pump function for end of suction and blow out function for cleaning purposes
- High level of safety by currency connector
- High qualitative ECG recordings by consequently shielded patient leads
- Changeable removable suction leads
- Ag/AgCl suction electrodes with flexible silicone guarantee optimal adhesive force, even for patients with strong hair growth
- Length of suction leads 100 cm precordial and 130 cm extremal
- Optional: Rechargeable battery vacuum pump for mobile operation for the
DT 100 series
DIFFERENT DT 80 B & DT 100 Models
DT 80 B plus |
DT 80 T plus |
DT 100 B plus |
DT 100 T plus |
DT 100T Table mounting |
DT 100 TH with trolley |
DT 100 B Table mounting |
DT 100 T with trolley MW 1260-50 |
Technical data:
| DT 80 B and DT 80 T series | DT 100 B and DT 100 T series | |
| Functional principle | Vacuum buildup by pump | Vacuum generation by pump |
| Electrodes | Silver / silver chloride | Silver / silver chloride |
| External material | Soft silicone | Soft silicone |
| Standard wires | Chest 100 cm Extremities 130 cm |
Chest 100 cm Extremities 130 cm |
| Connector | SUB D 15-pin, IEC standard Connection cable for various all ECGs available |
SUB D 15-pin, IEC standard Connection cable for various all ECGs available |
| Vacuum range | 60 – 200 mbar | 60 – 260 mbar |
| Battery operation | N/A | optional |
| Versions available | Stand model with wheels Various trolley mounting versions Table mounting versions Wall mounting versions |
Stand model with wheels Various trolley mounting versions Table mounting versions Wall mounting versions |
| Safety | MDR Class I / IEC 60601-1 | MDR Class I / IEC 60601-1 |
| Power supply | 230V~/50Hz (24V) | 230V~/50Hz (24V) |
| Power input | 40VA | 40VA |
